What are the raw materials for continuous casting production process?

2023-08-21 15:29


Plug rod, long nozzle and submerged nozzle are three functional refractories used in the continuous casting production process. Except a small amount of submerged nozzle is fused silica, most of them are aluminum carbon materials. Therefore, the raw materials for continuous casting production process can be divided into four types: main raw materials, graphite raw materials, additives and binders. Due to the significant impact of raw materials on the performance of products, there are strict requirements for the particle size, purity, and structure of raw materials in the continuous casting production process. Below, Qingdao Saileo editor will explain to you.


1. Main raw materials

Main raw materials mainly include various corundum raw materials, fused magnesia, spinel, fused zirconia, fused silica and fused mullite. The selection of main raw materials depends on the different products and parts to choose different main raw materials. The commonly used raw materials are corundum or high aluminum raw materials, and the slag line is made of partially stable fused zirconia raw materials. Corundum, fused magnesium oxide, spinel, and other materials can be selected for the stopper rod head and the bowl of the nozzle according to the different steel grades of continuous casting. Quartz and mullite are introduced as raw materials to improve thermal shock stability. Generally, the raw material particle size of the aggregate is required to be less than 1mm.


2. Graphite raw material

The extensive use of graphite in continuous casting products is to ensure high thermal shock resistance and corrosion resistance, but the adverse effect of using graphite is that the product is prone to oxidation. Therefore, in order to prevent graphite oxidation and improve the corrosion resistance of the product, high-purity flake graphite is often used.




3. Additives

In order to improve the performance of continuous casting products, a certain amount of modifying additives, such as antioxidants, are often added to the ingredients. Commonly used antioxidants include metal aluminum powder, silicon powder, silicon carbide, boron carbide, Al Si, and Al Mg alloy powder. The addition of additives is sometimes utilized to enhance the performance of materials such as SiC, Si3N4, AlN, etc. that generate non oxides during the heat treatment process; Alternatively, during use, it can be oxidized before graphite, reducing CO to C and inhibiting the consumption rate of C in the product; Or generate C and oxides, increase the density of refractory materials, form a protective layer, promote graphite crystallization, and improve the high-temperature strength of products.


4. Organic binder

The binders used in continuous casting are all resins, including phenolic resin and furfural phenolic resin. These resins are used to form carbon bonds after heat treatment, resulting in high strength of the product. Therefore, it is required that the resin should have high residual carbon, suitable viscosity, and stable performance. The amount of resin added is usually between 5% and 10%.

The above is the content about the raw materials for continuous casting production process shared by the editor of Qingdao Sailiou. We hope it can be helpful for you. For more information, please visit Sailiou's official website at www.zircool365.com
